Cooper & Hunter Midnight Black 6,000 BTU Indoor Wall Mount, 230V, R410A - Ductless Mini Split Air Conditioner Heat Pump
Cooper & Hunter Midnight Black 6,000 BTU Indoor Wall Mount, 230V, R410A - Ductless Mini Split Air Conditioner Heat Pump
Summary
The option to choose both, aesthetics and functionality is brought by Cooper&Hunter’s Olivia Midnight indoor wall-mounted mini split series. The sleek black panel design offers an alternative option to the standard, white-colored units. The Olivia Midnight series works as a single or multi-zone mini split unit. Auto-swing horizontal louvers maintain an even airflow throughout the room while some additional notable features include “Follow Me” mode, “Sleep” mode, “Timer” options, and 46°F Freeze Protection. Olivia Midnight models can be controlled with the included C&H remote control, or via any smart device when used in conjunction with Cooper&Hunter’s optional Smart Kit and the C&H Remote app. This series of mini splits is available in 6K, 9K, 12K, 18K, and 24K Btu/h models and can be paired with Regular or Hyper Heat Pump Outdoor Units. The Genius Core Technology enables the unit to operate with an ultra-low compressor speed of 12Hz for extra energy savings granting them a rating of up to a 26.4 SEER2. These systems can heat and cool your home or office effectively down to -13°F for Standard units and even down to -22°F for Hyper units.
Important
All units must be installed by a licensed HVAC professional for the warranty to be valid. Registration is required within 60 days of installation and can be completed online or by phone. The installation kit is necessary for the system to function. Ensure that you have selected the desired installation kit above. This kit comes with Pre-Flared 99% Copper Lines, Data Communication Wires, PVC Drainage Attachment, Wrapping Bands, etc.
What's Included
- Indoor Unit CH-B06MOLVWM-230VI (6,000 BTU Olivia Midnight Black Indoor Wall Mount Unit)
- Wi-Fi Adapter (17310900A05963)
- Optional, Pre-Flared 99% Copper Installation Kit (16ft, 25ft or 50ft.) MUST BE SELECTED ABOVE.
- Wireless Remote Controls
- Installation Manual
- User’s Manual
- Manufacturer Warranty
Compatible Standard Outdoor Units
| Capacity | BTU | SKU |
| Dual (2) Zone: | 18,000 BTU | CH-18MES-230VO |
| Dual/Tri (2 or 3) Zone: | 28,000 BTU | CH-28MES-230VO |
| Dual/Tri/Quad (2, 3 or 4) Zone: | 36,000 BTU | CH-36MES-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 48,000 BTU | CH-48MES-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 55,000 BTU | CH-55MES-230VO |
Compatible Hyper Outdoor Units
| Capacity | BTU | SKU |
| Dual (2) Zone: | 19,000 BTU | CH-HPR19M-230VO |
| Dual/Tri (2 or 3) Zone: | 28,000 BTU | CH-HPR28M-230VO |
| Dual/Tri/Quad (2, 3 or 4) Zone: | 36,000 BTU | CH-HPR36M-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 48,000 BTU | CH-HPR48M-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 55,000 BTU | CH-HPR55M-230VO |
Sizing and Compatability:
Combination Chart
The capacity and number of systems can vary for each outdoor unit. Consult the combination chart for potential loading configurations. Ensure the total capacity of all connected indoor units aligns with the minimum and maximum loading range of the selected outdoor unit. It is not mandatory to utilize all circuits on an outdoor unit; some circuits may remain sealed without an attached indoor unit.
Warranty
- 7 year compressor limited warranty
- 5 year parts limited warranty (must be installed by a licensed HVAC technician)
- 1 year remote control
Technical Information
Model Number: CH-B06MOLVWM-230VI
| Specification | Details |
|---|---|
| Power Supply | 208~230V, 60Hz, 1Ph |
| Rated Capacity | 6,000 BTU/h |
| EER2 | 15 |
| SEER 2 | 23.5 |
| Refrigerant Type | R410A |
| Suitable Area | 150-250 SQ FT |
| Indoor Air Flow (Turbo/Hi/Mi/Lo) | 294/247/176/141 |
| Sound Level (Hi/Lo) | 38.5/33/20.5 |
| Dimensions | 28.70x7.87x11.50 |
| Net/Gross Weight | 17.64/22.49 lbs |
| Cooling | 60 ~ 90°F |
| Heating | 32 ~ 86°F |
| Liquid Side/Gas Side | 1/4" / 3/8" |
Certifications
Performance Data/Features
- Auto-Swing for horizontal
louvers - Genius Core ultra-low
compressor speed of 12Hz - 46° Freeze Protection
- Turbo Mode
- Self-Clean Function
(Single-Zone only) - Eco Mode (Single-Zone only)
- Follow Me Mode
- Remote Control included
- Smart Kit ready with downloadable C&H remote app
